TMHVS-1000MDT-XY Semi-automatic Micro Vickers Hardness Tester

Main Features:

1.The x-y axis automatic displacement platform is controlled by built-in stepping motor, which is controlled by mouse click,

with high positioning accuracy, good repetition accuracy, fast moving speed and high working efficiency.

2.The system can be used as a whole or alone, with high flexibility.

3.The software system can control the automatic loading platform to program and move, and a variety of measurement modes

can be selected, especially suitable for the measurement of carburizing and nitriding depth.

4.All data is saved permanently, and inspection report can be generated automatically.
